Produktportfolio / Knowles, Brand SYFER / MLCC

Auflistung der MLCC von Knowles, Brand SYFER

Knowles, Brand SYFER

115Vac 400Hz MLCCs

  • self heating
  • MIL-STD-704
  • FlexiCap™ available
  • C0G/NP0 dielectric
  • 0805 to 2220 case size

Knowles, Brand SYFER

250Vac non-safety range of MLCCs

  • X7R dielectric
  • up to 120nF
  • C0G/NP0 dielectric
  • 0805 to 2220 case size

Knowles, Brand SYFER

AEC-Q200 Approved Products

  • X2Y integrated passive component
  • multilayer chip capacitors (with FlexiCap™ termination)
  • 3 terminal EMI chips

Knowles, Brand SYFER

Class X & Y Surge & Safety Capacitors

  • Sizes 1808, 1812, 2211, 2215 and 2220
  • Meet Class Y2/X1, Y3/X2 and X2 requirements
  • approved for mains ac voltages, up to 250Vac
  • approved by UL and TÜV

Knowles, Brand SYFER

Copper Barrier capacitors

  • X7R dielectric
  • non-magnetic
  • High Q - High Frequency
  • C0G/NP0 dielectric
  • 0402 to 2225 case size

Knowles, Brand SYFER

FlexiCap™ polymer termination

  • special termination to reduce the typical root causes of mechanical stress cracking
  • C0G/NP0 dielectric

Knowles, Brand SYFER

High Frequency Capacitors (Hi Q range)

  • various termination options including FlexiCap™
  • Temperature Coefficient (Typical) 0 ± 30 ppm/°C
  • Operating Temperature -55°C to +125°C
  • insulation resistance at +25°C >100GΩ
  • 0402 to 3640 case sizes

Knowles, Brand SYFER

High Temperature X8R Capacitors

  • X8R dielectric
  • Temperature Coefficient of Capacitance (TCC) ± 15% from -55°C to +150°C
  • insulation resistance (IR) 100G Ω or 1000secs (whichever is the less)
  • Capacitance Range 1.0nF ~ 1.8Ã�¼F
  • 0805 to 2225 case size

Knowles, Brand SYFER

High Voltage capacitor range extension

  • X7R dielectric
  • 0805 to 1812 case size
  • 0805 case size available

Knowles, Brand SYFER

High Voltage MLCCs for LCD Inverter Applications

  • X7R dielectric
  • Suffixcodes FB9
  • C0G/NP0 dielectric
  • 1808 and 1812

Knowles, Brand SYFER

High Voltage SM Capacitors 10Vdc - 6kVdc

  • X7R dielectric
  • X5R dielectric
  • C0G/NP0 dielectric
  • 630V to 6kV
  • 0603 to 8060 case size

Knowles, Brand SYFER

High Voltage SM Capacitors 4kV - 6kV Range

  • X7R dielectric
  • C0G/NP0 dielectric
  • 1808 to 2225 case size

Knowles, Brand SYFER

High Voltage SM Capacitors Tip & Ring/Ring Detect capacitors

  • suitable as replacements for high voltage leaded film capacitors, thereby saving pcb board space and weight
  • Small surface mount package compared to traditional through hole capacitors
  • Improved temperature performance compared to film capacitors
  • FlexiCap™ available

Knowles, Brand SYFER

High Voltage SM Capacitors with High Dielectric Withstand Voltage

  • These ratings are based on an application of the DWV voltage for a period of up to 60 seconds (where the charging current is limited to 50mA)
  • high dielectric withstand voltages (DWV) of 1.5kV and 2.5kV
  • Case sizes 1206 to 2225
  • Capacitance values from 4.7pF to 120nF
  • C0G/NP0 dielectric

Knowles, Brand SYFER

IECQ-CECC Approved Multilayer Ceramic Capacitors

  • X7R dielectric
  • surface mount technology
  • C0G/NP0 dielectric
  • 16V to 1kV
  • 0603 to 2225 case size

Knowles, Brand SYFER

Low Profile Capacitors

  • silver/palladium or nickel barrier terminations
  • maximum thicknesses of 0.50mm, 0.60mm and 0.65mm
  • C0G/NP0 dielectric
  • 25V/ 50V
  • 0805, 1206, 1210 case size

Knowles, Brand SYFER

Multilayer Ceramic Capacitors for Space Applications

  • S02A and S05 Space ranges
  • 0603 to 2225 case size

Knowles, Brand SYFER

Open Mode Capacitors

  • X7R dielectric
  • FlexiCap™ available
  • 16V to 250V
  • 0603 to 2225 case size

Knowles, Brand SYFER

Standard Multilayer Ceramic Capacitors 10Vdc to 6kVdc

  • multilayer construction
  • dc rated
  • C0G/NP0 dielectric
  • 0603 to 8060 case size
  • 0,47pF to 22µF

Knowles, Brand SYFER

Tandem Capacitors

  • X7R dielectric
  • FlexiCap™ available
  • 16V to 250V
  • 0603 to 2225 case size
